Dragster 60R
Specification
Specification
| Specification | Details |
|---|---|
| Distributor | Stomp Distribution LTD |
| Manufacturer | EBOX |
| Model | Dragster 60R |
| Frame Design | Full duplex high strength steel frame, removable motor plate, integrated chain tensioner, loop tail design, quick-release battery system, 2-point foot peg mounts, frame-mounted stunt peg compatible |
| Bar Risers | Cast Alloy 36mm Rise Ø22.2 |
| Handlebar | 2 Piece 29.5" × 7" |
| Motor | 60V EBX PMSM Motor with Temperature Feedback and Encoder |
| Motor Voltage | 60V |
| Peak Power | 5.2KW (6.7hp) |
| Rated Power | 4.5KW |
| Max RPM | 8,500 |
| Battery | 60V 26Ah Battery with BMS (18650 Cells), Steel Case, QS8 Connector and Air Breaker Switch |
| Controller | 80 Amp Fardriver Controller |
| Charger | AC 100–240V, Output 67.2V, 5A |
| Charge Time | 4–5 Hours |
| Range Per Charge | 25–28 Miles (40–45 Km) |
| Throttle | SURRON Style Full Twist |
| Display | TFT Odometer Display with 3 Speed Modes and Fault Code Analysis |
| External Adjustability | 3 Riding Modes |
| Front Suspension | Rigid Forks |
| Wheel Size | 6 / 6 |
| Tyres | 145/70-6 SUNF Fast SM Tyres |
| Front Brake | Hydraulic Disc (Right Lever), Wavy Rotor 160mm, 6 Bolt 48mm BCD |
| Rear Brake | Hydraulic Disc (Left Lever), Wavy Rotor 160mm, 6 Bolt 48mm BCD |
| Gearing | Front 10T, Rear 55T |
| Chain | 219H 108L |
| Top Speed | 53 mph (85 Km/h) |
| Waterproof Rating | IP54 |
| Connectors | Automotive Connectors with Sealed Wiring Harness |
| Other | USB A + C Charging Ports |
| Wheelbase | 882 mm |
| Ground Clearance | 120 mm |
| Seat Height | 585 mm |
| Built to Race | B2R |
| Warranty | EBX 1 Year / 1000 Miles (whichever comes first) Powertrain Warranty + 6 Month Parts Warranty |
Size and Fit
Size and Fit
About the brand
Stomp
Dragster 60R
Product details
THE EBX Dragster is FINALLY HERE! In a world full of limp, slow, plastic failures, comes a truly HARDCORE electric minibike with more steeze than should be legal in such a miniature package.
Featuring insane top speeds of up to 55 mph, the EBX is now delivered with a SERIOUS safety warning: Do Not Ride if You are Easily Frightened.
Choose from 3 ballistic powertrains and multiple mind-blowing colourways. Fully re-engineered and reconsidered with a temperature protected PMSM encoder motor, 80 Amp Fardriver controller, bigger batteries, bigger brakes and 3-mode smart TFT colour display.
Other exciting features are available such as bronze inverted suspension forks, an integrated LED headlight and luxury suede printed seats. The EBX range firmly cements the Dragster as the “Ultimate Wheelie Weapon” and King of the streets.
