Kayo K6-R
Specification
Specification
| Kayo K6-R Enduro Specifications | |
|---|---|
| Distributor | Stomp Distribution LTD |
| Manufacturer | KAYO |
| Model | K6-R |
| Warranty | 12 Months |
| Engine | |
| Type | 4-Stroke, DOHC, Liquid-Cooled |
| Valves | DOHC, 4-Valve, Balance Shaft |
| Displacement | 249.6cc |
| Bore x Stroke | 77.0 x 53.6 mm |
| Compression Ratio | 11.6:1 |
| Fuel System | Carburettor FCR38 |
| Max Power | 28.0 kW @ 10500 RPM |
| Max Torque | 23.7 Nm @ 8000 RPM |
| Transmission | |
| Clutch | Wet, 5 Disc |
| Ignition | CDI |
| Starting System | Electric & Kick |
| Transmission | Manual 6-Speed (1-N-2-3-4-5-6) |
| Final Drive | D.I.D 520H 116L |
| Chassis | |
| Frame | Chromoly Cradle Frame |
| Rear Subframe | Alloy |
| Swing Arm | Alloy 595mm |
| Handlebar | Alloy 7075 |
| Footpegs | Stainless |
| Exhaust | Stainless Ø30–40mm Performance |
| Silencer | Stainless Ø08–40mm |
| Steering Head Angle | 27° |
| Suspension | |
| Front Suspension | USD 950mm Forks (Adjustable Compression & Rebound) |
| Rear Suspension | 480mm Adjustable with Linkage |
| Trail | 138mm |
| Wheels & Brakes | |
| Front Rim | Alloy 7116 21 × 1.60" |
| Rear Rim | Alloy 7116 18 × 2.15" |
| Rim Lock | Front & Rear |
| Front Tyre | 80/100-21 Kenda |
| Rear Tyre | 110/90-18 Kenda |
| Front Brake | Dual Piston – Ø270 mm Disc – Braktec |
| Rear Brake | Single Piston – Ø240 mm Disc – Braktec |
| Dimensions | |
| Vehicle Size | 2145 x 815 x 1240 mm |
| Wheelbase | 1488 mm |
| Ground Clearance | 350 mm |
| Seat Height | 950 mm |
| Dry Weight | 113 kg |
| Fuel Capacity | 7.5 Litres |
| Packing Size | 1870 x 540 x 1080 mm |
| Wheel Size | 21 / 18 |
Size and Fit
Size and Fit
If you are looking for competition level specification out of the crate at a price that’s not going to require you to re-mortgage your house, we have you covered with the K6-R Enduro.
But don’t let the price fool you, we are as aggressive at the track as we are at the market.
From forest to track and everything in between, the KAYO K6-R is a full-sized dirt bike that can do it all.
Featuring a highly trackable 250cc 4-Stroke liquid cooled engine with DOHC coupled to a 6-speed box, the drivetrain is well suited to the technical trails with enough grunt to put a smile on your face when railing a berm or pulling flat-out on a straight.
KYB fully adjustable suspension soaks up the rough stuff and thanks to many lightweight high-specification alloy parts and a 4130 main frame, the bike’s weight is kept to an absolute minimum.
Details such as a lithium battery, electric and kick-start and LED lighting as standard demonstrate just how well considered this competition level machine is.
At Kayo we have a whole team of high-level endurance riders who put in the miles day after day at our test tracks to make certain our bikes can compete reliably with the best in the world. We will stop at nothing to ensure you are considering a Kayo as your next bike.
| Distro | Stomp Distribution Ltd |
| Manufacturer | KAYO |
| Model | KT50 mini |
| Warranty | 6 months limited warranty (engine not included) |
ENGINE
| Engine | 2-Stroke, air cooled |
| Valves | n/a |
| Displacement | 50.2cc |
| Bore x Stroke | 40.0 × 40.0mm |
| Compression Ratio | 12.3:1 |
| Fuel System | Carburetor Dellorto 19mm |
| Max Power | 6.2 kw @ 9250rpm |
| Max Torque | 6.35 Nm @ 9250rpm |
| Ignition System | CDI |
| Startin System | Electric, kick |
| Tramsission | Fully automatic |
| Final Drive | Chain 420 106L |
CHASSIS
| Frame Design | Steel cradle frame |
| Rear Subframe Design | n/a |
| Swing Arm | Steel |
| Footpegs | Steel |
| Steering Head Angle | 27° |
| Handlebar | Alloy |
| Exhaust | Stainless |
| Silencer | Stainless |
| Front Suspension | USD 625mm forks (non-adjustable) |
| Rear Suspension | 275mm shock (non-adjustable) |
| Trail | 59mm |
| Front Rim | Alloy 10x1.6" |
| Rear Rim | Alloy 12x1.4" |
| Rim Lock | n/a |
| Front Tyres | 2.50-12 |
| Rear Tyres | 3.00-10 |
| Front Brake | Dual piston - Ø190 mm disc |
| Rear Brake | Single piston - Ø190 mm disc |
DIMS AND CAPACITY
| Vehicle Size LWH | 1445 x 680 x 980mm |
| Wheelbase | 1035mm |
| Ground Clearance | 185mm |
| Seat Height | 630mm |
| Dry Weight | 48kg |
| Fuel Capacity | 3.5 litres |
| Packing Size LWH | 1300 x 380 x 735mm |
About the brand
Kayomoto
Kayo K6-R
Product details
If you are looking for competition level specification out of the crate at a price that’s not going to require you to re-mortgage your house, we have you covered with the K6-R Enduro.
But don’t let the price fool you, we are as aggressive at the track as we are at the market.
From forest to track and everything in between, the KAYO K6-R is a full-sized dirt bike that can do it all.
Featuring a highly trackable 250cc 4-Stroke liquid cooled engine with DOHC coupled to a 6-speed box, the drivetrain is well suited to the technical trails with enough grunt to put a smile on your face when railing a berm or pulling flat-out on a straight.
KYB fully adjustable suspension soaks up the rough stuff and thanks to many lightweight high-specification alloy parts and a 4130 main frame, the bike’s weight is kept to an absolute minimum.
Details such as a lithium battery, electric and kick-start and LED lighting as standard demonstrate just how well considered this competition level machine is.
At Kayo we have a whole team of high-level endurance riders who put in the miles day after day at our test tracks to make certain our bikes can compete reliably with the best in the world. We will stop at nothing to ensure you are considering a Kayo as your next bike.
