Stomp FXJ 110 Manual
Specification
Specification
| Stomp FXJ 110 Manual Specifications | |
|---|---|
| Distributor | Stomp Distribution LTD |
| Manufacturer | Stomp |
| Model | FXJ 110 Manual |
| Warranty | 6 Months (Parts Only) |
| Engine | |
| Type | YX110, 4-Stroke, Air-Cooled |
| Valves | SOHC, 2 Valve |
| Displacement | 106.7cc |
| Bore × Stroke | 52.4 × 49.5 mm |
| Compression Ratio | 9.0:1 |
| Fuel System | Carburettor 19mm Nibbi |
| Max Power | 5.1 kW @ 8000 RPM |
| Max Torque | 7.2 Nm @ 5000 RPM |
| Ignition | CDI |
| Transmission | |
| Clutch | Wet, 3 Disc |
| Starting System | Kick Start |
| Transmission | Manual 4-Speed (N-1-2-3-4) |
| Final Drive | 420 Chain |
| Chassis | |
| Frame | Lightweight Steel Spine Frame |
| Swing Arm | Steel 390 mm |
| Handlebar | Lightweight Steel |
| Footpegs | Steel |
| Suspension | |
| Front Suspension | Non-USD 630 mm Forks |
| Rear Suspension | 270 mm (Adjustable Pre-load Shock) |
| Wheels & Brakes | |
| Front Rim | Steel Rims with SDG Hubs 14" |
| Rear Rim | Steel Rims with SDG Hubs 12" |
| Front Tyre | 60/100-14 |
| Rear Tyre | 80/100-12 |
| Front Brake | Hydraulic 190 mm Disc |
| Rear Brake | Hydraulic 180 mm Disc |
| Dimensions | |
| Wheelbase | 1085 mm |
| Ground Clearance | 275 mm |
| Seat Height | 740 mm |
| Dry Weight | 60 kg |
| Fuel Capacity | 3.5 Litres |
| Wheel Size | 14 / 12 |
Size and Fit
Size and Fit
About the brand
Stomp
Stomp FXJ 110 Manual
Product details
Stomp FXJ 110 is the perfect entry level bike for field racers and back yard thrashers. Simple to get to grips with but surprisingly fast, the manual 110cc 4-stroke engine packs a serious punch that will leave your mates far behind in your dust. This is the manual version, so perfect for those clutched race starts, or for popping wheelies and practising your gear changes.
Conceived and refined for fun, but capable of so much more; the FXJ features our secret in house geometry and gains privileged access to our special edition engines (that are only built for Stomp).
Built by the biggest factory in the world with the best possible components available. Robot welders, spotless floors, test tracks and highly trained staff who are proud to build Stomp!
All our bikes are test ridden prior to being broken down for shipping, so you know you are getting the absolute best bike money can buy from a reputable brand who will look after you with full spares back up for many years to come.
At Stomp, we have been perfecting this bike for almost 20 years, so the question remains, why would you waste your money on a Stomp FXJ copy, when you can have the real thing?
