Stomp Z3-160
Specification
Specification
| Distributor | Stomp Distribution LTD |
|---|---|
| Manufacturer | Stomp |
| Model | Z3-160 Big Wheel |
| Warranty | 6 months, parts only |
| Engine | ZS155, 4-stroke, oil cooled |
| Valves | SOHC, 2 valve |
| Displacement | 155.5cc |
| Bore x Stroke | 60 x 55mm |
| Compression Ratio | 11.5:1 |
| Fuel System | Carburettor 26mm Nibbi |
| Max Power | 10.5 kW @ 9500 RPM |
| Max Torque | 11.5 N·m @ 8000 RPM |
| Clutch | Wet, 3 disc |
| Ignition | CDI |
| Starting | Kick start |
| Transmission | Manual 4-speed (N-1-2-3-4) |
| Final Drive | 420 chain |
| Frame | Light-weight steel spine frame |
| Rear Subframe | CRF70 subframe |
| Swing Arm | Steel 430mm |
| Footpegs | Upgraded PRO Footpegs |
| Handlebar | Light weight steel |
| Front Suspension | USD 735mm forks (non-adjustable) |
| Rear Suspension | 290mm piggy back shock (adjustable preload) |
| Front Rim | Steel rims with SDG hubs 17" |
| Rear Rim | Steel rims with SDG hubs 14" |
| Tyres | Front: 70/100-17, Rear: 90/100-14 |
| Brakes | Front: Hydraulic 210mm wavey disc, Rear: Hydraulic 180mm wavey disc |
| Wheelbase | 1240mm |
| Ground Clearance | 320mm |
| Seat Height | 865mm |
| Dry Weight | 74kg |
| Fuel Capacity | 5.5 litres |
| Wheel Size | 17/14 |
| Packing Size | 1560 x 380 x 735mm |
Size and Fit
Size and Fit
About the brand
Stomp

Stomp Z3-160
Product details
The Z3-160 is currently the most powerful Stomp in the range. Packing a whopping 17hp at the rear wheel, this is a serious weapon and not for beginners. The bike is supplied with big 17/14 wheels as it simply has too much power for a 14/12 configuration. The single cylinder engine from ZS was designed to scream like a banshee and holy shi** does it deliver!
Back in 2007 Stomp were the first to take the legendary YX140 engine and squeeze it into a pit bike named “SuperStomp 140”. This absolute killer combination of an aftermarket frame and bonkers engine put Stomp firmly on the map. Ever since, Stomp fans and customers have been going crazy for their pit bikes, making Stomp a globally recognised brand. The Z3-160 was designed as the bike to carry on the tradition of ‘too much power in a small bike’.
The chassis is a lightweight single backbone frame with cradle to keep the bikes mass down. This makes it faster and nimbler than many other brands focusing on MX looks at the cost of performance. The suspension is simple yet effective with plenty of travel. There’s even scope to upgrade the rear shock should you feel the need to start hitting some heavier jumps. The USD forks and triple clamps complete the look.
The Z3-160 follows the trend for larger pit bikes, more space on the bike, yet still a lot of fun to throw around. Aggressive visual cues, clean lines and highly distinctive factory graphics complete a well-balanced looking bike that’s tasteful yet means business. This bike will blow your socks off and leave your mates far behind.
This is a true Surron killer for a fraction of the money, so TURN UP THE VOLUME AND SMELL THE PETROL BRAAAP!
